Simonswerk Tectus TE 541 3D FVZ Concealed Hinge

£145.65£220.50



For unrebated residential and heavy-duty doors with recessed frames



SKU: TE 541 3D FVZ Categories: , , Tag:

Product Description

Product Features:

  • FVZ = for recessed frames
  • Recessed frames up to 14 mm
  • Concealed hinge system
  • For timber, steel, or aluminium frames
  • For unrebated heavy-duty doors
  • Sideways closed hinge body for a homogeneous mortise appearance
  • 3D adjustment (side +/- 3.0 mm, height +/- 3.0 mm, compression +/- 1.0 mm)
  • Maintenance-free slide bearings

Technical Details:

  • Load capacity – 100.0 kg
  • Overall length – 185.0 mm
  • Width (door part) – 28.0 mm
  • Width (frame part) – 28.0 mm
  • Cutter diameter – 24.0 mm
  • Collar ring diameter – 30.0 mm
  • Opening angle – 180°

Suitable for:

  • Type of door leaf – Timber, Metal
  • Rebate – Unrebated
  • Type of frame – aluminium frame, blind frame, block frame, casing frame, steel frame

Hinges are priced as singles.
The load capacity mentioned above refers to the use of 2 hinges per door leaf (1 x 2 m).
With an opening position of 180° the door may have to be fixed additionally.
Fixings included.

TECTUS FVZ   Datasheet ⬀
TE 541 3D FVZ   Datasheet ⬀
TE 541 3D FVZ   Product Selector ⬀

Read more

Estimated delivery time between 2-3 working days.

Additional information

Finish

, , , , , , , , , , , , , ,
